mdinterface

mdinterface is a Python package for building systems for Molecular Dynamics (MD) simulations. Initially developed for electrolyte/electrode solid-liquid interfaces, it is equally suited for pure solvent boxes, mixed-solvent electrolytes, and polymer networks.

Features

  • Layer-by-layer SimCell builder: add slabs, solvent regions, and vacuum gaps one step at a time; call .build() when done.
  • ASE & MDAnalysis integration: the assembled box converts to ase.Atoms or mda.Universe with a single call, ready for any downstream tool.
  • Multi-solvent support: mix solvents by molar ratio + density, ratio + total count, or explicit per-species molecule counts.
  • Ion placement: dissolve ions by count, molar concentration, or a spatially-varying concentration profile.
  • PACKMOL integration: handles molecular packing automatically; tolerance and dilation are tunable per layer.
  • Configurable stacking axis: build along Z (default) and permute to X or Y at the end.
  • Polymer builder: generate chains of arbitrary length from a monomer Specie.
  • AIMD with FAIRChem: run ML-potential dynamics via FAIRChem (optional).
  • RESP charges: estimate partial charges with PySCF / gpu4pyscf (optional).
  • Force-field database: pre-defined parameters for common metals, noble gases, water models, and ions; or generate OPLS-AA parameters on the fly with LigParGen.
  • LAMMPS output: writes data files and force-field coefficient blocks ready to run.

Warning

The documentation is still under construction and might contain mistakes.

Example

from mdinterface import SimCell
from mdinterface.database import Water, Ion, Metal111

# set up your species
water = Water(model="ewald")
na    = Ion("Na", ffield="Cheatham")
cl    = Ion("Cl", ffield="Cheatham")
gold  = Metal111("Au")

# build the simulation cell
simbox = SimCell(xysize=[15, 15], verbose=True)
simbox.add_slab(gold, nlayers=3)
simbox.add_solvent(water, solute=[na, cl], nsolute=[5, 5], zdim=25, density=1.0)
simbox.add_slab(gold, nlayers=3)
simbox.build(padding=0.5)

# write output files
simbox.write_lammps("data.lammps", atom_style="full", write_coeff=True)

See the Quick Start page for more examples, or jump straight to the User Guide.
